Woodpecker Style Dental Air Polisher Supragingival & Subgingival

The PerioPulse Sandblasting Scaler All-in-One Machine is a multifunctional dental cleaning system that integrates:

• Gingival cleaning

• Ultrasonic scaling

• Root canal cleaning

• Sandblasting polishing

• Internal pipeline cleaning

It is designed for clinical dental use, offering efficient, painless, and safe cleaning with a user-friendly touchscreen interface.

✅ Multi-Mode Operation – Switch freely between Gingival, Periodontal, Root Canal, Sandblasting, and Cleaning modes.
✅ Touchscreen Control – 7.0-inch HD touch panel for intuitive operation and real-time status display.
✅ Titanium Alloy Tips – Non-damaging to enamel and bone structure.
✅ Automatic Frequency Tracking – Ensures stable performance and optimal vibration.
✅ High-Temperature Sterilizable – Handpieces withstand 134°C and 0.22MPa sterilization.
✅ Heated Sandblasting – Enhances patient comfort during polishing.
✅ Dual-Language Support – English and Chinese interface.

• Input Power: 220V 50Hz, 88VA

• Vibration Frequency: 30 ± 5kHz

• Output Power: 3W–20W

• Water Pressure Range: 0.1–0.5MPa

• Air Pressure Range: 0.55–0.75MPa

• Water Temperature (Sandblasting): 0–45°C

• Safety Class: Class I, Type B, IPXO (host), IPXI (foot switch)

1. G-Mode (Gingival Cleaning) – Removes surface stains and plaque.

2. P-Mode (Periodontal Cleaning) – Deep cleans periodontal pockets (≤5mm).

3. E-Mode (Root Canal Cleaning) – Uses ultra-fine tips for canal irrigation.

4. A-Mode (Sandblasting Cleaning) – Removes stubborn plaque and stains with aerosolized powder.

5. C-Mode (Pipeline Cleaning) – Flushes internal tubing to prevent clogging and bacterial growth.

⚠️ Contraindications:

• Not for patients with hemophilia, pacemakers, or severe respiratory conditions.

• Use with caution for cardiac patients, pregnant women, and children.

⚠️ Safety Precautions:

• Always wear protective goggles and masks during sandblasting.

• Never point the sandblasting nozzle at people.

• Ensure tips are tightly fastened before use.

• Use only distilled or demineralized water.

• Regular Cleaning: Execute C-Mode after each use to prevent crystal buildup.

• Tip Replacement: Replace worn tips when vibration efficiency drops or visible damage occurs.

• Common Issues:

  • No vibration/water: Check power and foot switch connection.

  • Weak vibration: Tighten or replace tip.

  • Sandblasting issues: Check powder level, nozzle blockage, or O-ring seal.

For unresolved faults, contact authorized distributors or the manufacturer.

• Host unit, power adapter, foot switch

• Scaler handpiece & sandblasting handpiece

• Titanium alloy tips (scaling, polishing, root canal)

• Water bottle, sand powder jar, PU tubing

• Tool set (wrenches, O-rings, user manual)

This device is intended for use by trained dental professionals only.
For further details, refer to the full user manual or contact customer support.
